FEATURES
| Functional principle | Photoelectric retro-reflective sensor | ||||||||
| Functional principle detail | With minimum distance to reflector (dual lens system) | ||||||||
| Sensing range max. | 0.03 m ... 6 m 1) | ||||||||
| Sensing range | 0.07 m ... 5 m 1) | ||||||||
| Polarisation filters | Yes | ||||||||
|
|||||||||
|
|||||||||
| Adjustment | Potentiometer, 270° | ||||||||
| Special applications | Hygienic and washdown zones | ||||||||
ELECTRONICS
| Supply voltage UB | 10 V DC ... 30 V DC 1) | ||||||||||||||
| Ripple | ± 10 % 2) | ||||||||||||||
| Current consumption | 30 mA 3) | ||||||||||||||
| Protection class | III | ||||||||||||||
|
|||||||||||||||
| Output function | Complementary switching output | ||||||||||||||
| Circuit protection |
A 7) B 8) D 9) |
||||||||||||||
MECHANICS
| Housing | Rectangular | ||||||
| Dimensions (W x H x D) | 15 mm x 44 mm x 22 mm | ||||||
| Connection | Male connector M8, 4-pin | ||||||
|
|||||||
| Weight | 40 g | ||||||
