Hobo Voltage Input Lead Set
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Overview
A voltage lead set with alligator clips that is used to wire a WattNode terminal block connected to a WattNode KWH transducer and the voltage terminals in a circuit breaker panel.
Features
- Prewired to WattNode terminal block
- Precludes mis-wiring to KWH transducer
- No need for user to choose and supply own wiring
- Safety and convenience
Specifications
Colors (cables and clips): Black, blue, green, red, white
Alligator clips: Insulated nickel plated brass, sheathed banana plug receptacle
Cable length: 5 feet
Suitability: Single phase circuits 120-277vac, and three phase circuits 208-480vac.
Temperature rating: -25 C to 80 C
Electrical rating: IEC 61010-031 @ 1,000V CAT II , 600V CAT III P2
